The GLYPH Capture+ combines USB4 connectivity with a dedicated CFexpress Type B slot for fast card offloads and direct media workflows. Its 40Gb/s connection supports transfer speeds up to 5,000 MB/s when paired with compatible cards and computer hardware.
A solid aluminum core and outer shell provide fanless heat dissipation during sustained transfers. The removable protective cover adds protection for travel and field production, while bus-powered operation eliminates the need for an external power supply.
Key features
- Transfer speeds up to 5,000 MB/s
- USB4 connectivity with up to 40Gb/s bandwidth
- Dedicated CFexpress Type B card slot
- Designed for sustained card offloads and direct editing
- Solid aluminum core and outer enclosure
- Fanless passive heat dissipation
- Rugged removable protective cover
- Compact, bus-powered design
- Compatible with USB and Thunderbolt-equipped computers
- 30 cm USB-C cable included
Connection compatibility
Maximum performance requires a compatible 40Gb/s USB4 connection and sufficiently fast CFexpress media. The reader can connect to compatible USB 3.0, Thunderbolt 3, Thunderbolt 4, and Thunderbolt 5 systems, but actual transfer speeds depend on the memory card, computer, connection, and workload.
Included
- GLYPH Capture+ CFexpress Type B card reader
- 30 cm SteadyIO USB4 USB-C to USB-C cable
- Rugged removable protective cover
Specifications
- Supported media: CFexpress Type B
- Interface: USB4
- Connector: USB-C
- Maximum interface bandwidth: 40Gb/s
- Maximum transfer speed: Up to 5,000 MB/s
- Power: USB bus powered
- Cooling: Fanless passive heat dissipation
- Reader dimensions: 3.38 Ă— 3.38 Ă— 0.91 inches
Warranty
- Three years of hardware coverage, including the cable
- One year of advance replacement
